免费咨询鄂式破碎机被广泛用于抗压强度320兆帕以下的各种物料的粗碎、中碎作业。该破碎机已广泛运用于矿山、冶金、化工、建材、公路、铁路、水利等行业。
技术参数
| 型号 | 给料尺寸(mm) | 出料口尺寸(mm) | 生产能力 ( t/h) | 电动机功率(kw) | 外型尺寸(mm) |
| PE150x250 | ≤130 | 15-45 | 1-4 | 5.5 | 896x745x935 |
| PE250x300 | ≤150 | 15-55 | 3-6 | 7.5 | 1050x987x1000 |
| PE250x400 | ≤210 | 25-60 | 5-20 | 15 | 1215x1520x1030 |
| PE400x600 | ≤350 | 40-100 | 15-60 | 30 | 1650x1588x1050 |
| PE500x750 | ≤425 | 50-100 | 40-110 | 55 | 1956x1918x1920 |
| PE600x900 | ≤500 | 60-125 | 90-180 | 75 | 2290x2206x2370 |
| PE750x1060 | ≤630 | 60-150 | 110-380 | 110 | 2531x2455x2783 |
| PE900x1060 | ≤700 | 100-160 | 230-390 | 110 | 2900x2657x2950 |
| PE900x1200 | ≤750 | 110-165 | 220-450 | 132 | 3100x2760x3260 |
| PE1000x1200 | ≤900 | 110-185 | 315-500 | 132 | 3200x2760x3260 |
| PE1200x1500 | ≤950 | 115-195 | 400-800 | 220 | 3710x3446x4075 |
| PE1500x1800 | ≤1200 | 135-225 | 500-1000 | 280 | 5100x4700x4300 |
| PEX150x750 | ≤120 | 10-40 | 8-25 | 15 | 1310x1118x1145 |
| PEX250x750 | ≤210 | 15-50 | 15-35 | 22 | 1400x1751x1515 |
| PEX350x750 | ≤300 | 15-50 | 18-40 | 30 | 1485x1680x1648 |
| PEX250x1000 | ≤210 | 15-60 | 15-60 | 30 | 1550x1964x1380 |
| PEX250x1200 | ≤210 | 15-60 | 20-60 | 37 | 1530x1946x1380 |
| PEX300x1300 | ≤250 | 25-60 | 16-105 | 55-75 | 2000x2320x1730 |
